3-HOUR FIRE RATEDContinuous Prep Doors
Doors pre-prepared for continuous hinge applications, ideal for high-traffic commercial openings.
Specifications
| Gauge | 16, 18 |
| Core | Polystyrene |
| Thickness | 1¾" |
| Prep Type | Continuous hinge prep (full-length hinge cutout) |
| Material | Galvanized Steel A40/G90 |
| Heights | 6'8", 7'0", 8'0" |
| Widths | 2'0" – 4'0" |
| Fire Label | 3hr / PP / S |
Hardware Prep Options
C161
Bored/Cyl Knobset, 1-1/8" × 2-1/4" front, 2-3/4" backset
ASA
4-7/8" ASA with lip, standard location
M86
Edge cutout, 1-1/4" × 8" front, mortise lock
BR
Internal reinforced for surface rim panic device
IAZ
Flush bolt, automatic or manual
Key Features & Benefits
Special locations, hinge sizes and lock preparations available upon request
Compatible with Steelcraft, Curries, Mesker, Pioneer, and CECO hinge locations
Build Your Part Number
Build Your Part Number
Format
HM-[gauge]GCP-[hinge]-[size][prep]
Example
HM-16GCP-SC-3070C161
Need Continuous Prep Doors?
Contact our team for pricing, lead times, and custom configurations.
